Homelift TNE - PHx Series
At the cities in whole country, more and more storey residential houses have been being build. All family
members, especially elder, weakly peolpe, prenault women and their baby need to move to living spaces in comfordable & quite safety.
Thien Nam Homelift PHx series meets effectively requirements of small hoistway for almost private houses that space have to save stair or other neccessary purposes. the hoistway's plan is only about 1.0m 2 and propably smaller. Therefore, arranging the Homelift TNE - DPH in the shophouse have got advantage than other elevators.
Home lift TNE not only a high class utility, a pressed point of your decorated space which also usefull for increasing in the interaction and communication between family gennerations, bringing the happy life every day to all your family members.
The need of improve our living space decorating into a more fashionable space are becoming more and more popular. Elevator's hoistway with profile steel frame with glass rubber seal and splints gives a more softed, brilliance look to the house inside moving space.
Full Selective Collective operation: during operation, lift serves calls from the landings in moving direction, service calls from the landings in opposite direction afterwards. When lift arrive at landing, illumination of corresponding button will be off.
Car door safety device
This device makes doors open automatically while closing to aim preventing passengers or other objects knocked against doors
Over load warning
When car load exceeds rated load, indicator is on, a buzzer sounded and lift is prevented from starting
Arrival announcement
Indicator displays the landing floor, a buzzer sounded
Car fan and light turn-off Automatically
For energy saving, car fan and light turn off automatically in case there is no hall call or car call
Automatic Rescue Device
In case of power failure, lift will be sent to the nearest floor by DC power of battery, door open for passenger getting off
Emergency light
In case of power failure, emergency light on car ceiling turned on automatically
Emergency call with ephone
In case of emergency, press the ephone button located on car operating panel to automatic dial for connecting with responsible persons that numbers had been setup
Indicators
Matrix indication lights with orange color to ease for elderly, poor eyesight and eye-color sick people, then also indicating the present status of elevator in Vietnamese/ English/ Japanese/ Chinese
Automatic Re-leveling
The elevator will be automatically to get leveling with the landing oor when sudden changing loads
Car call cancelation
If making wrong calls, the passengers can cancel the calls inside the car
Bypass outside calls
If the hall buttons damaged, then this function can bypass the outside calls. (Error of the sticky buttons)
